Listed in increasing size order from 1/2 Pint to 600 gallons.

Partial listing updated August 9, 2018. We have more to offer not listed here.

Brand

Model

Stock #

Descripiion

Photos

&

Videos

Ross High Shear Planetary Mixer Explosion Proof for Hazardous Locations Class 1 Groups D & F

PD-40Suitable

Stock # UR40AC01

IN STOCK AS OF JULY 26, 2018

Description: Used 40 Gallon Ross PD-40 Gallon Powermix High-Shear Planetary Mixer

- One (1) Used 40 Gallon Ross PD-40 Gallon Powermix HighShear Planetary Mixer

- Motors & controls are suitable for use in hazardous location for Class 1, Groups D & F
- stainless steel product contact parts
- Comes with a standard rectangular mixing blade and a high-speed disperser shaft, the blade is currently missing.
- Vacuum hood, with multiple ports, a vacuum port and gauge as well as a light.
- Comes with one 40-gallon non-jacketed mixing can fitted with an outlet on front tank wall.
Mix cans mounted on casters.Controls are enclosed in two explosion proof boxes suitable for hazardous locations Class I, Groups D & F
- Drive is raised and lowered by an air over oil hydraulic lift with an air tank on the mixer base
- Prior use was at a chemical products company.
- Mixer has been test run and was reported to be in good operating condition.

<USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS>

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS MIXER POWERMIX EXPLOSION PROOF HAZARDOUS LOCATIONS PD-40

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS MIXER POWERMIX EXPLOSION PROOF HAZARDOUS LOCATIONS PD-40

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS

USED ROSS PLANETARY MIXER HAZARDOUS LOCATIONS CLASS I GROUP F G POWERMIX 40 GALLONS





Myers 250 Gallon Dual Shaft Vacuum Mixer, Model V550AH-20-30-1539

IN STOCK AS OF JUNE 13, 2018



Myers Dual Shaft Vacuum Mixer, Model V550AH-20-30-1539:

- The mix cans measure 44" ID X about 44" Deep which results in a volume of about 283 US Gallons. Six
- The mix cans have a jacket rated for 14 PSIG
- The anchor agitator has three wings with scrapers along the sides and bottoms.
- The high-speed disperser agitator is driven by a 30 HP inverter duty motor with speed control.
- The 3-wing anchor agitator, with wipers, is driven by a 20 HP inverter duty motor with speed control.
- The mixer is designed for operation under vacuum
- The mixer originally had a third agitator, but it has been removed. The port is still there if you wanted to add another mixer.
- The mixer was new in 2005.
- The mixer comes with 1mix can as follows:
- Product contact area is made from stainless steel.
- Fitted with a carbon steel 14 PSI Jacket
- Fitted with a 2" side discharge near the inside bottom
- Mix can is mounted on casters

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

Used Myers Dual Shaft Vacuum Mixer V550AH-20-30-1539

In Stock

Components & Tanks for Ross Mixers

We currently have in stock used tanks for Ross mixers in the following sizes:

1, 2, 4, 10, 40 and 200 gallons.

We also have dust shields for 4 and 10 gallon Ross mixers..

We can fabricate new tanks and discharge presses as well. Inquire for details



Ross Mixer

LDM-1/2PT

HALF PINT DOUBLE PLANETARY MIXER

Stock # UR1/2PTAC01





Sold and I want buy yours.

Used Ross Double Planetary Mixer, model LDM-1/2PT Half Pint with HV BLADES

- Used Ross Double Planetary Mixer, model LDM-1/2PT Half Pint with HV BLADES

- Designed for operation under vacuum.

- Vacuum hood is fitted with 2 sight/charging ports.

- Contact parts are made of stainless steel.

- Fitted with two with HV BLADES, High Viscosity agitator blades.

- Agitator is controlled by an Reliance SP500Variable Frequency Drive.

- Tank is fitted with a stainless steel jacket

- Tank has one handle to facilitate the installation and removal of the small tank. Thank is secured in place by a sefuring device under the tank.

- Prior use is with a pharmaceutical company.



Ross Mixer

DPM-1QT

Stock # UR1QTAC01

IN STOCK AS OF JUNE 13, 2018



Used Ross Double Planetary Mixer, model DPM-1QT 1 Quart with HV BLADES

- Used Ross Double Planetary Mixer, model DPM-1QT 1 Quart with HV BLADES

- Designed for operation under vacuum.

- Vacuum hood is fitted with 2 sight/charging ports.

- Contact parts are made of stainless steel.

- Fitted with two with HV BLADES, High Viscosity agitator blades.

- Agitator is controlled by an ACTech Variable Frequency Drive.

- Tank is fitted with a stainless steel jacket and a side entering thermocouple.

- Drive system and agitators are raised and lowered by a hydraulic lift.

- Mounted on a painted steel bench with casters.

- Prior use is with a pharmaceutical company.

Used Ross Mixer Model DPM-1QT 1 QUART

ROSS DOBLE PLANETARY MIXER HV BLADES

ROSS DOBLE PLANETARY MIXER HV BLADES

WebSitePhotos/Used_Ross_DPM-1_QT_Double_Planetary_Mixer_A4T.jpg

ROSS DOBLE PLANETARY MIXER HV BLADES

ROSS DOBLE PLANETARY MIXER HV BLADES

ROSS DOBLE PLANETARY MIXER HV BLADES

Ross Mixer

PD-1/2 Gallon

Stock # UR1/2AC01

IN STOCK AS OF JUNE 13, 2018



Used Ross Powermix, PD-1/2 Gallon with Press, Model DS-1/2 Gallon

- Used Ross Powermix, PD-1/2 Gallon, High Shear Planetary Mixer

- Designed for operation under vacuum.

- Contact parts are made of stainless steel.

- Fitted with one standard rectangular profiled agitator blade.

- Fitted with one high speed disperser agitator.

- Scraper blades are provided for both the tank bottom and vertical side.

- Each agitator is controlled by a Variable Frequency Drive.

- Tank is designed for use with a discharge press and is fitted with a stainless steel jacket, a cove cut plug valve and a side entering thermocouple.

- Drive system and agitators are raised and lowered by a hydraulic lift.

- Mounted on a painted steel bench with casters.

- Prior use is with a pharmaceutical company.

- Discharge press is suitable for discharging product from a suitable 1/2 gallon mix can included with this mixer.

- Press platen is raised and lowered by the included hydraulic power pack.

- Prior use is with a pharmaceutical company.



USED ROSS 1/2 GALLON POWERMIX HIGH SHEAR PLANETARY MIXER

USED ROSS POWERMIX HALF GALLON PWERMIX

USED ROSS 1/2 GALLON POWERMIX HIGH SHEAR PLANETARY MIXER

USED ROSS 1/2 GALLON POWERMIX HIGH SHEAR PLANETARY MIXER

USED ROSS DISCHARGE PRESS HALF GALLON



SYMEX

5 LITER LAB PROCESSOR

STOCK # US5AD01





IN STOCK AS OF JUNE 13, 2018

Used Symex 5 Liter Laboratory Vacuum Mixing and Homogenizing System

Unit to include the following features and specifications:

AGITATING AND HOMOGENIZING SYSTEM:

Agitation system for mixing and homogenizing medium to high viscosity formulations
consists of one top-entering centrally located agitator and one top entering homogenizing rotor/stator turbine.

VACUUM VESSEL:

5 Litet Stainless steel removable mixing vessel with a flat bottom. Designed for operation from -1 to +2 Bars

Vessel jacket is designed for ab temperature of 151 C and 6 Bars. The unit has an integral hot water heating unit.

VACUUM COVER:

Vessel Cover manufactured of stainless steel.
Agitator and cover assembly are raised and lowered by an integral lift system for the removal of and ease of access to the
vessel and its contents. The cover includes:

Cover gasket embedded in the cover for vacuum sealing.

Flange for central agitator.

Flange for mounting optional homogenising agitator and for product addition.

Sight port witnh wiper.

Cover fitted with light.

Connection for vacuum.

VACUUM SYSTEM:

Air-ejector vacuum system installed in the mono-block cabinet.

CONTROLS:

The control panel includes temperature controls for both the product and jacket.

Start / Stop and speed control.

Fitted with an analog speed readout.

Input Voltage: 110 volts, 1 phase, 60 Hz.

Click on images to enlarge.



Used Symes 5 Liter Vacuum Lab Processor Mixer

Used Symes 5 Liter Vacuum Lab Processor Mixer

Used Symes 5 Liter Vacuum Lab Processor Mixer

Used Symes 5 Liter Vacuum Lab Processor Mixer

Used Symes 5 Liter Vacuum Lab Processor Mixer









Ross Powermix Mixer

Model: PD-2 Gallon

Stock # UR2AK01

IN STOCK AS OF JUNE 13, 2018



USED ROSS HIGH SHEAR DOUBLE PLANETARY MIXER, MODEL PD-2 GALLON, POWERMIX WITH TWO AGITATORS, ONE LOW SHEAR AND ONE HIGH SPEED DISPERSER. MIXER HAS T-304 STAINLESS STEEL CONTACT PARTS. 1/3HP EXPLOSION PROOF HYDRAULIC LIFT DRIVE. 1HP 70-240 RPM VARIABLE SPEED PLANETARY DRIVE. 2HP 1140-3420 RPM 3/60 460 VOLT VARIABLE HIGH SPEED DISPERSER DRIVE. ELECTRIC HYDRAULIC LIFT CHANGE CAN REMOVAL DESIGN. FEATURES VACUUM HOOD ON BOWL. JACKET CHANGE CAN. PREVIOUSLY USED IN A LABORATORY.

Ross

LDM-2 Gallon Double Planetary Mixer

Stock #

UR2AC03

• Used Ross double planetary mixer, model LDM-2 Gallon

• Comes with 2 mix cans

• Designed for operation under vacuum, comes with vacuum pump.

• Mounted on a steel bech with casters.

• Older unit but nice looking. A great example of the longevity of Ross equipment!

We buy Used Ross LDM-2 Gallons Double Planetary Mixer

We buy and we sell Used Ross LDM-2 Gallon Double Planetary Mixer

We buy and we sell Used Ross LDM-2 Gallon Double Planetary Mixer

We buy and we sell Used Ross LDM-2 Gallon Double Planetary Mixer

We buy and we sell Used Ross LDM-2 Gallon Double Planetary Mixer

We buy and we sell Used Ross LDM-2 Gallon Double Planetary Mixer



Ross Discharge Press Model DS-2

Stock #

URP2CME01



Discharge press for use with Ross 2 gallon mix cans suitable for use with a discharge press.



Photos upon request

Ross Mixer

DPM-4 Gallon

Stock # UR4F01

Sold and I want buy yours.



- Used Ross DPM-4 Double Planetary Mixer

-Contact parts are stainless steel

- Unit is designed for operation under vacuum

- 1 quart to 4 gallon capacity

- Vacuum cover and drives are raised by a hydraulic lift system

- Vacuum cover has two sight and charging ports and an FNPT vacuum port

- Mixer comes with one jacketed mix can with a thermocouple, bottom discharge and casters.

-Two sets of agitator blades with one pair being the standard and the othe paur being flat plates.

- Controls include a VFD

- Prior use is with a pharmaceutical company.

Used Ross DPM-4 Gallon Double Planetary Mixer Kynar Coated

Used Ross DPM-4 Gallon Double Planetary Mixer Kynar Coated

Used Ross DPM-4 Gallon Double Planetary Mixer Kynar Coated

Used Ross DPM-4 Gallon Double Planetary Mixer Kynar Coated

Used Ross DPM-4 Gallon Double Planetary Mixer Kynar Coated

Used Ross DPM-4 Gallon Double Planetary Mixer Kynar Coated















Wanted: Your Surplus Ross Mixers

We rebuild, click here to see typical examples of the work we do.

Ross Mixer

LDM-4 Gallon

Stock # UR4ACD05





Ross LDM-4 Gallon double planetary mixer.

• Ross LDM-4 Double Planetary Mixer
• Stainless Steel contact parts

• Unit is desiegned for operation at atmospheric condition

• 1 quart to 4 gallon capacity

• Dust cover and drives are raised by hand tilting

• Dust cover has a charging chute

• Mixer comes with one mix can



This item is in stock.

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer

Used Ross LDM-4 gallon double planetary mixer









Archem Press for Ross 4 Gallon Mixers

Model: DS-4 Gallon

Stock # NA4AM01





PRESS IN STOCK AS OF JUNE 13, 2018

• New Archem discharge press for use with either Ross or Archem 4 gallon mixers.

Scott Turbon Double Planetary Mixer

5 Gallons

Stock #

UST5AC01

IN STOCK AS OF JUNE 13, 2018



Used Scott Turbon Double planetary mixer with discharge press:

- 5 gallon working capacity

- Designed for operation under vacuum

- Change can design.

- Comes with a flat bottom tank and a cone bottom tank.

- Tank is fitted with a stainless steel jacket, a discharge valve.

- Comes with a special cart to hold & move the tanks

.Used 5 Gallon Scott Turbon Double Planetara Mixer

Used 5 Gallon Scott Turbon Double Planetara Mixer

Used 5 Gallon Scott Turbon Double Planetara Mixer

Click to see Mixer Video 1

Click to see Mixer Video 2

Ross Versamix Tripple Shaft Mixer

PVM-10 Gallons

Stock #

UR10AC02

IN STOCK AS OF JUNE 13, 2018



Description: Mélangeur d'occasion Ross, modèle PVM-10 Gallon avec 3 agitateurs

• Un (1) mélangeur d'occasion de 10 gallons Ross avec 3 agitateurs, modèle PVM-10
• surfaces de contacts fabriqués d'acier inoxydable
• Muni d'un agitateur en forme d'ancre avec 3 palles munies de grattoirs pour balayer le fond et les parois de la cuve
• Muni d'un agitateur de type disperser à haute vitesse
• Muni d'un agitateur de type rotor-stator pour émulsionner
• Le couvercle avec les agitateurs se lève et se baisse avec l'aide d'un système de levage hydraulique activé pair une source d'air comprimé.
• Le couvercle est muni de 2 hublots, une sortie pour évacuer l'air avec une jauge à vide.
• La cuve à une chemise chauffante en acier inoxydable conçue pour une pression de 50 livres/pouces carrés.
• Le panneau de contrôle est muni d'interrupteurs en/hors pour chaque agitateur, un arrêt d'urgence et un interrupteur de puissance principal
• Ce mélangeur fut antérieurement utilisé pour faire des crèmes pour soins personnels.
• Ce mélangeur a été vérifié et fonctionne bien. J'en ai vu le vidéo.

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10

USED ROSS VERSAMIX PVM-10





Click on images to enlarge.

Jaygo Saturn

Nauta Type Mixer

JN-FF-5-MO

45 Liters

SOLD, we need another unit. Sell us yours.



Another kind of planetary mixer with its own advantages. This mixer will perform better than a double planetary mixer giving much better and faster top to bottom mixing than a double planetary mixer. I will also mix a a much smaller relative partial batch. Discharge is easier with its conical shape and emptying can be accelerated by reversing the rotation of the auger to puch the product down and out the bottom outlet.



Vacuum Planetary Mixer with approximately 12 US Gallon Capacity:

This may be a good alternative to a double planetary mixer.

Jaygo Saturn Stainless Steel Conical Screw Mixer
Manufacturer Jaygo Manufacturing Inc
Year 1999
Model FF-5-MO
Serial Number 2678
Capacity Size 45 L
Current Application Out of Service
Spare/Change Parts N
Manual Available No
Shipping Weight 750 LBS
Runs on 230 volts, 3 phase, 60 Hz.

Formerly used by a pharmaceutical company.

JAYGO NAUTA TYPE VERTICAL CONE BLENDER PHOTO A

JAYGO NAUTA TYPE VERTICAL CONE BLENDER PHOTO B

JAYGO NAUTA TYPE VERTICAL CONE BLENDER PHOTO C

JAYGO NAUTA TYPE VERTICAL CONE BLENDER PHOTO E

JAYGO NAUTA TYPE VERTICAL CONE BLENDER PHOTO D







Ross Double Planetary Mixer

HDM-10 Gallons

Stock #

UR10ACDM01

IN STOCK AS OF JUNE 13, 2018



• Ross HDM-10 Double PlanetaryMixer.


• Mixer base is enclosed and hydraulic lift area is enclosed with bellows

• Unit is fitted with a control pannel

• Up to 10 gallon mix capacity

• Dust cover and drives are raised by an air over oil hydraulic lift

• designed for operation at atmospheric pressure
• Mix can is jacketed, has a 2" bottom flush ball valve and is fitted with a thermocouple
• Unit has been test run and is in good operating condition

Click here to see a video of the unit in operation.

Click on images to enlarge.

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO A2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO B2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO C2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO D2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO E2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO G2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER PHOTO H2

USED ROSS HDM-10 GALLON DOUBLE PLANETARY MIXER F2HOTO A



Ross Powermix Double Planetary Mixer

PD-10 Gallons

Stock #

UR10AC01



YT

IN STOCK AS OF JUNE 13, 2018

• Used Ross PD-10 Double Planetary Mixer
• Stainless Steel contact parts
• One rectangular profile mixing blades

• One high speed disperser
• Up to 10 gallon mix capacity
• designed for operation under vacuum
• vacuum cover and drives are raised by an air over oil hydraulic lift


Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto A

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto B



Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto D

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto E

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto F

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto G

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto H

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto J

Ross Powermix High Shear Planetary Mixer Model PD-10 Gallon PHoto K









Jaygo High Shear Planetary Mixer

MPVDV-60

Stock #

UJ45AC01

IN STOCK AS OF JUNE 13, 2018



Description:

Manufacturer: Jaygo
Model #: MPVDV-60
Year: 1999
S/N: 2669
Capacity: Approximately 45 litres or 11.8 US Gallons working capacity
Mix Cans: Two vacuum jacketed mix cans with centrally located flush ball valve and thermocouple. Each mix can has a removable base with casters.
Agitators: Two planetary agitators with pitched blades and one centrally located high speed disperser. There are two spare planetary agitator blades.
Scrpaer: There is a scraper arm assembly which is included but it is not show in the photos.
Spare Parts: Comes with a spare planetary gear box and some spare mixing blades.
Control Panel: Under construction due to conversion to 230/460 volts, includes new motors

45 Liter Jaygo High Shear Planetary Mixer

45 Liter Jaygo High Shear Planetary Mixer

45 Liter Jaygo High Shear Planetary Mixer

45 Liter Jaygo High Shear Planetary Mixer

45 Liter Jaygo High Shear Planetary Mixer

45 Liter Jaygo High Shear Planetary Mixer

45 Liter Jaygo High Shear Planetary Mixer

ROSS DPM-40 Gallon Double Planetary Mixer

IN STOCK AS OF JUNE 13, 2018



• Used Ross DPM-40 Double Planetary Mixer
• Stainless Steel contact parts

• Drive has a 30 hp motor
• Two rectangular profile mixing blades. We can make our improved HV-Type High Viscosity blades if required.
• 40 gallon mixing capacity

•Unit comes with one stainless mix cans with a flush plug valve on the bottom.

• Nice clean unit from a sanitary application



Click her to see video of mixer running

40 Gallon Double Planetary Mixer

with optional Discharge Press

Stock #

NHDPM40AC01

Description:

Final assembly this week of March 14, 2016

This mixer is being built for stock and is available for purchase & it can be customized.

- New 40 Gallon Double Planetary Mixer
- Stainless Steel contact parts including planetary gearbox

- Unit is designed for operation under vacuum
- Two standard rectangular profile mixing blades
- 40 gallon working capacity with bottom discharge near front edge
- Tank suitable for use with a discharge press

- Comes with one tank, additional tanks available

-Optional new discharge press



Under construction.



Tank & Discharge Press for us with 40 Gallon Ross Mixer We have been making our own tanks and presses for the useds Ross mixers we sell for nearly 20 years. The video link at left will show you a recently made 40 gallon tank and press.

Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper



Stock #

UB50AC01

IN STOCK AS OF JUNE 13, 2018

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

• Used Bowers Vacuum Paste Mixer, model 10 HP Paste Mixer

• Mixer was new in 2005 and used for only 2 to 3 years and the product manufacturing was dropped.

• Designed for a 15,000 centipoise product with a specific gravity of 1.8

• Product contact parts are made from type 304 Stainless Steel except for the polyethylene scrapers.

• 51 US Gallon working capacity, 75 US Gallon full holding capacity

• Fitted with an anchor agitator with scraper blades driven by a 10 HP, 575 Volts, 3 Phase, 60 Hz motor

• Agitator speed is controlled by a Variable Frequency Controller.

• Anchor agitator is of a quick release design.

• Change can design. Comes with a cart to hold and move the tank from and to the mixer and other locations.

• Comes with 1 mix can with a dished bottom and a 4 inch PMB flush ball valve, and lifting lugs for lifting with tank lifting assembly.

• Comes with tank lifting assembly to be used to lift the tank for manoeuvring above place of discharge like moulds by customer's overhead lifting device.

• Agitator drive and vacuum hood are raised and lowered by the air over oil hydraulic lift system.



Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper



Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper

Description: Used Bowers 50 US Gallon Vacuum Mixer with Single Shaft Anchor-Scraper



Ross Vacuum High Viscosity Mixer Reactor with Double Hellical Agitator

HSM-40 Gallons

Stock # UR40ACO2



IN STOCK AS OF JUNE 13, 2018

1-USED ROSS APPROX. 40 GALLON VACUUM MIXER REACTOR EITH DOUBLE HELLICAL AGITATOR. UNIT HAS AIR/OIL LIFT MECHANISM TO RAISE AND LOWER THE DRIVE TO ALLOW THE REMOVAL OF THE MIX TANK. DESIGNED FOR OPERATION UNDER VACUUM & A POSITIVE PRESSURE OF 35 PSI @ 350°F, JACKET MAXIMUM ALLOWABLE WORKING PRESSURE 100 PSI @ 350°F. MINIMUM DESIGN METAL TEMPERATURE 0°F AT 100 PSI. ROSS METAL FABRICATORS S/N 11801-1, national board 463, CRN 15925. STAINLESS STEEL CONTACT PARTS. JACKETED HAS PROVISION FOR THERMOCOUPLE, INSULUATED WITH SHEATHING.

This item is in stock.

This can be a substitute for a double planetary mixer, this unit will handle many of the double planetary mixer applications and perform better in particular when top to bottom mixing is critical, this design can do it faster. Last used on an 800,000 cP product.

USED ROSS DOUBLE HELLICAL VACUUM BLENDER PHOTO A

USED ROSS DOUBLE HELLICAL VACUUM BLENDER PHOTO A2

In-Line Ross High Shear Mixing System

Ross HSM-425

25 HP

Stock # URIL25AC01

IN STOCK AS OF JUNE 13, 2018



Description:

One only used Ross In-Line Ross High Shear Mixing System comprised of an in-line Ross Mixer Emulsifier, model HSM-425, driven by a 25 HP motor.  The system includes a stainless steel tank which is attached to the in-line high shear mixer. Rated for vacuum and pressure with.  The powder is added to the liquid stream and circulated through the tank and high-shear mixer in a loop and part of the stream is diverted away from the loop and into the next step of your process.  The unit can also be operated in a closed loop batch system.  This 25 HP unit has a flow through rate of 350 USGPM based on water.

Will sell in-line mixer-emulsifier or the jacketed pressure vessel by itself.

- Prior use is with a pharmaceutical company.

USED ROSS IN LINE HIGH SHEAR MIXER EMULSIFIER MODEL HSM-425 PHOTO C

USED ROSS IN LINE HIGH SHEAR MIXER EMULSIFIER MODEL HSM-425 PHOTO B

USED ROSS IN LINE HIGH SHEAR MIXER EMULSIFIER MODEL HSM-425 PHOTO A

Used-Ross-Mixer-Emulsifier-HSM-425

Used-Ross-Mixer-Emulsifier-HSM-425



HMX Jacketed Tank with Inverted Anchor Agitator

Stock # UH55ACO1

IN STOCK AS OF JUNE 13, 2018



Description: Jacketed Mixing Tank with Inverted Anchor Agitator

One only used mixing tank as follows:

- Approximately 55 gallons capacity
- Approximately 26" ID X 26.25" Deep
- Stainless steel contact parts and jacket
- Bottom Entering agitator. The shaft is enclosed inside a pipe with the agitator mounted at the top, thus eliminating the need for a submersed seal. There is a seal at the top end of the shaft. The agitator is an inverted anchor hanging from the top of the shaft.
- Seal between the top end of the shaft and pipe enclosure
- Very thick wall on tank and jacket
Machined tope flange
- O-Ring chord grooves on lid flange to create a seal
- Approximately 3/16" thick lid with approximately 1/2" thick flange
- Clamps t secure removable lid
- 1 hp motor with reducer, runs on 460 volts, 3 phase, 60 Hz and aC Tech drive
- Looks like it could hold vacuum with the heavy gauge construction and sealing features but no official rating on the device

HMX Jacketed Stainless Steel Tank with

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end

HMX Jacketed Stainless Steel Tank with inverted anchor with seal at the top end











Ross Mixer

HDM-200 Gallons

Double Planetary Mixers

Stock # UR200AC02





This is a unit that we refurbished which has been sold. We just acquired the three units listed just below which we will remanufacture.

• Used Ross HDM-200 Double Planetary Mixer
• Stainless Steel contact parts

• Drive has a 30 hp motor
• Two rectangular profile mixing blades
• 200 gallon mixing capacity

•Unit comes with 2 stainless mix cans with steel jacket and a flush ball valve on the bottom.

• Nice clean unit

USED ROSS DOUBLE PLANETARY MIXER MODEL HDM-200 GALLON PHOTO A

USED ROSS DOUBLE PLANETARY MIXER MODEL HDM-200 GALLON PHOTO B

Ross Mixer

HDM-225 Gallons

Double Planetary Mixers

Three units with two sold and one still available

Stock #

UR225AC01, UR225AC02 & UR225AC03

We are rebuiding three 225 gallon double planetary mixers as follows:

• Used Ross HDM-225 Double Planetary Mixer
• Stainless Steel contact parts

• Drive has a 40 hp motor

• A new control panel with VFD speed control

• The planetary gearbox will be disassembled and refurbished as required.
• Two rectangular profile mixing blades
• 225 gallon mixing capacity, jacketed with a discharge valve a required.

•Unitwill be reconfigured with a new hydraulic lift amd base.

•If needed, we can also supply new tanks and a discharge press.

Two units are sold and one is scheduled for remanufacturing.

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer

Used Ross HDM-200 225 Gallon Double Planetary Mixer













ROSS PVM-600 Gallon Tripple Shaft Mixe

Stock #

UR600AC01

THIS MIXER HAS BEEN SOLD. I HAVE OTHER BUYERS, SELL ME YOURS.



•Sanitary grade Ross Versamix model PVM-600 gallon tripple shaft mixer

• 40 HP high speed disperser

• 40 HP high shear rotor-stator mixer-emulsifier

• The mixer is in very nice condition. It was built in 1997 and had low usage, including a 5 year period without use at all.

• Comes with control panel.



USED ROSS PVM 600

USED ROSS PVM 600

USED ROSS VERSAMIX PVM-600 GALLON SANITARY GRADE

USED ROSS VERSAMIX PVM-600 GALLON SANITARY GRADE

USED ROSS VERSAMIX PVM-600 GALLON SANITARY GRADE

USED ROSS VERSAMIX PVM-600 GALLON SANITARY GRADE

USED ROSS VERSAMIX PVM-600 GALLON SANITARY GRADE







K

We want to buy your large dual shaft mixers.

Visit our packaging equipment page for tube and sausage fillers.

Click here

Need a break? Click here to view an entertaining video

Jim, click the following for your inspection videos: Video 1Video 2 Video 3

Gabriel Tries Pepsi for the First Time Video
